Product introduction: Pour the apples into the conveyor belt feeding hopper of the elevator, and evenly transport them upward by the conveyor roller of the elevator, so that the apples are moved and rolled. First, it is transported to the manual selection section to select the bad apples; then it enters the queuing conveyor belt, which is sequentially transported to the fruit tray of the electronic scale, falls into the hopper according to the weight, and is transported to the basket (box).
- Detalhes do produto
- Dados técnicos
Modelo: CZ-5000B-3
Scope of application: weight sorting of oranges, pears, mangos, avocados, apples, mangosteens, peaches, tomates, etc..
Dimensions (length * width * height mm) 19000*1500*1100
Sorting level: 9 levels (maximum 12 levels)
Work efficiency: 30000 pcs/hour
Working power supply: 380V
Rated power: 5.5kw
Weighing range: 50-500g (error ± 2g)
Width of each outlet: 610milímetros
