Sorting machine/

Fruit weighing, packaging, sorting machine

Model: JGGG-3000B

Dimensions (length * width * height mm) 13850*2700*1220

Sorting level: 5 levels

Work efficiency: 2t/h

Working power supply: 380V

Rated power: 5kw

  • Product Details
  • Technical Data

Product introduction: The winter jujube weighing and grading machine is composed of a hoist and a grading machine. The hoist is automatically lifted. The rollers automatically rotate to achieve uniform feeding. There is a 3-meter fruit picking table on the rollers for workers to choose. Therefore, the classifier is a roller-type classifier. The roller-type classifier drives the rollers on the grading bed through the rotation of the screw shaft to move forward in parallel, and gradually increase the gap between the rollers, so as to achieve the corresponding winter date. The size of the winter jujube falls from the gap between the rollers to the fruit conveyor belt, and then enters the foam box to automatically weigh the weight. The customer can freely set the weight of each box according to the touch screen, and the weighed weight can be automatically transported On the powered roller, the size of the winter jujube can be graded.

Model: JGGG-3000B

Dimensions (length * width * height mm) 13850*2700*1220

Sorting level: 5 levels

Work efficiency: 2t/h

Working power supply: 380V

Rated power: 5kw
